BTD-E810(IOL-△Tj test)

Discrete Device IOL Burn-in System

The system is designed to meet AEC-101 spec. And can perform IOL test for discrete device such as diode, transistor, MOS FET etc.

Each DUT △Tj can be monitored during the whole test period.

K-factor tester →

Test Standard

Product Features

Advanced Burn-in Mode

Adopt power loading mode of adjusting Vd/Id,instead of using Body Diode Ih heating mode, which makes DUT fully tested.
Universal BIB

With Mother-Daughter board design, it only requires adjustment of sub-board to fit different packages. which reduce the long-term use cost.
DUT Tj Test

1,1 sample DUT △Tj detection per zone. 2, All DUT △Tj detection: Each DUT position configuring with function board
Drawer type air-cooled chamber

Inside with Horizontal air circulating design . Independent control of each chamber to keep from the mutual interference.

Product Parameters

Chamber: Dimension

60(L)*30(W)*12.5(H)(cm); Air circulating

Horizontal air circulating design;PWM fan control(Optional heating module); QTY.

16 sets

Capacity: Slot

16; DUT per slot

All DUTs △Tj test: 24 DUT positions; Sample DUT △Tj test: 80 DUT positions; Total capacity

284/1280 DUT positions

Power Supply: QTY.

8 sets; Output

0-60V / 2400W; multiple models available

Driver Board: QTY.

16pcs; Constant current source

Per slot 4 channels with 20A output each; Up to 60 A when parallel connection(for IGBT uni-transistor); Test voltage detection

Range：0.00V～99.9V；Accuracy：±1％＋0.01V; Test current detection

Diode Id range:0.1A～60.0A;Transistor/MOS Id range: 0 mA～400.0mA;Accuracy:1％＋1LSB; Vf detection accuracy

±0.5mV; Tj test

Range：20℃～175℃；Accuracy：1％＋1LSB; Im generation range/accuracy

0~99.9mA ; ±1％＋0.1mA

Burn-in Board: Structure

Universal mother board(3 types)+varies daughter board; Socket

With high temperature resistant, anti-oxidation and fatigue resistant materials; Dimension

290*600(mm)

Equipment: Dimension

1730W*1150D*1900H(mm); Electrical requirement

A.C.220V±10％ / 50Hz; Power/Weight

15KW / 700kg

Learn More: R & d & Manufacturing; After-sales Support; Sales And Service
